± (1 m + 0.1 % x length) for reflective incidents1 ± (3 m + 0.1 % x length) for non-reflective incidents 2ġm after the bulkhead connector when the bulkhead reflectance is 3 m after an incident when the incident reflectance is 10 m after the bulkhead connector or any prior incident when the bulkhead reflectance is <-35 dB and the reflectance of any prior incident is <-35 dB. Operating relative humidity (without condensation)ĩ5% (10✬ to 35✬) 75% (35✬ to 40✬) uncontrolled 11 dBĭistance accuracy (0 m to 1500 m or 0 ft to 4921 ft)

FLUKE NETWORKS FIBER QUICKMAP PRO

When and Where to Use Fiber OneShot PRO and Fiber QuickMapįiber OneShot PRO provides immediate and in-depth visibility into a singlemode fiber cable (below).įiber QuickMap operates the same, except on multimode fiber up to 1,500 meters / 4,921 feet.įluke Networks Fiber QuickMap Series Specifications Rugged construction vibration and drop tested to 1 meter.Long battery life, 1,500 tests (typical) from 2 AA alkaline batteries.Optional LC, ST and FT interchangeable adapters are available.Key information visible on a large display power loss in db and distance in meters or feet.

Measure and locate high loss connections and breaksįeatures common to both Fiber OneShot PRO and Fiber QuickMap.

Locate severe bends, high-loss splices, breaks and dirty connectors in singlemode fiber Measure and locate high-loss splicesįind potential sources of high bit error rates caused by reflectance from dirty or poor connections Measure up to 4,921 feet (1,500 metres) of fiber in seconds Locate the end of a fiber Backlighted display turns off automaticallyĩ/125µm and 62.5/125 µm 850 nm output wavelength

Change the Index of Refraction (IOR) to improve fiber length accuracy.

Six-second test time-no more blind troubleshooting that can waste hours Connect your fiber and press the Test button.

Detects live optical signals before it begins testing.

Find potential sources of high bit error rates caused by reflectance from dirty or poor connections.

Locate severe bends, high-loss splices, breaks and dirty connectors in singlemode fiber.

Using a shorter fiber launch cable may hide the first. Measure up to 4,921 feet (1,500 metres) of fiber in seconds In order to get the best results with the Fiber QuickMap, especially visibility into the first event, we recommend the use of a high quality, low loss, and low reflectance fiber launch cable of at least 100 meters with the appropriate connector for the first connection into the link under test. NOTE: Fluke Network lead times can vary due to component and supply issues.

Visible in dark areas.Fluke FQM-100-M Fiber Quickmap Kit multimode Fault Finder (Item no.

Measure up to 4,921 feet (1,500 metres) of fiber in seconds The Fiber QuickMap has the simplicity of a VFL, and provides distance and power information on high losses, breaks, and the end of the fiber. Optical Time Domain Reflectometers (OTDR) provide graphical data and analysis along the entire length of a cable, way beyond the reach of a VFL, but they can be expensive and require more time and skill to operate.įluke Networks FQM-M Fiber QuickMap fills the gap between a VFL and an OTDR. They are not very helpful for cable runs more than a few meters, or when the cable is not visible or accessible, or when the laser light can’t penetrate the jacket.

FLUKE NETWORKS FIBER QUICKMAP PATCH

VFLs work well for exposed lengths of fiber near a patch panel by illuminating bad connections and breaks. Like an OTDR, a laser sends light pulses through the fiber and measures the power and timing of light reflected from high loss connections and splices, and the end of the fiber.

Fluke Networks FQM-M Fiber QuickMap measures length and identify high loss events on multimode fiber optic cable.
